RSS
Round Straight Steel Pole
Pantheon steel poles are ideal for commercial, industrial, municipal, and retail applications requiring a high quality and cost effective pole to support lighting, banners, security devices, and other pole mounted site elements. Pantheon poles are made of weldable grade cold rolled carbon steel tubing conforming to ASTM A500 Grade B. Fabricated to the highest standards Pantheon poles come in round and square straight steel versions as well as round tapered to meet your application needs. Hot rolled carbon steel base with anchor bolts ensure a strong and dependable mounting. Standard or custom drill mount and tenon mount options are easy to specify along with crossarms and coupling options and electrical box details for a complete offering.
ORDERING INFORMATION
LUMINAIRE
MODEL
HEIGHT
GAUGE
BUTT Ø
BASE
MOUNTING
ELECTRICAL BOX
ACCESSORIES & OPTIONS
FINISH
RSS
Round
Straight
Steel Pole
8
8 Foot
​
10
10 Foot
​
12
12 Foot
​
14
14 Foot
​
16
16 Foot
​​
18
18 Foot
​​
20
20 Foot
​
22
22 Foot
​​
25
25 Foot
​
30
30 Foot
​​
35
35 Foot
11G
11-Gauge
​
7G
7-Gauge
__*
*See spec sheet chart on page 2 to make butt diameter selection. Then, enter the selected dimension here. For example, if 4.5-inches is chosen, "4.5" should be entered.
4
4-Bolt Base
TENON MOUNTING
D000
No Drilling
​
D190
1 @ 90°
​
D290
2 @ 90°, 180°
​
D218
2 @ 90°, 270°
​
D390
3 @ 90°, 180°, 270°
​
D490
4 @ 0°, 90°, 180°, 270°
​
DCUS
Custom; Specify Orientation and Height
​
T204
2 3/8" OD x 4" Tenon
​
T304
2 7/8" OD x 4" Tenon
​
T356
3 1/2" OD x 6" Tenon
​
T406
4" OD x 6" Tenon
​
TCUS
Custom; Specify Orientation and Height
FA
30" Up @ 180°
​
FB
30" Up @ 0°
​
FC
30" Up @ 90°°
​
FD
30″ Up @ 270°
​
FE
36″ Up @ 180°
​
FF
36″ Up @ 0°
​
FG
36″ Up @ 90°
​
FH
36″ Up @ 270°
​
FI
24″ Up @ 180°
​
FK
24″ Up @ 90°
​
FL
24″ Up @ 270°
​
FZ
Custom; Specify Orientation and Height
C12
Threaded Coupling 1/2″
​
C34
Threaded Coupling 3/4″
​
C10
Threaded Coupling 1″
​
EHH
Extra Handhole
​
GF1
Duplex GFCI Receptacle with Cover
​
GF2
Duplex GFCI Receptacle with In-Use Cover
​
LAB
Less Anchor Bolts
​
LPC
Less Pole Cap
​
PAB
Pre-Shipped Anchor Bolts
​
VD2
Vibration Dampener: 2nd Mode
POWDER COAT
GALVANIZED
BA
Black
​
BH
White
​
BM
Dark Bronze
​
BV
Dark Green
​
GC
Grey
​
XX
Custom RAL Color
​
1Q
Galvanized Only
​
1C
Black Powder Coat over Galvanizing
​
1D
White Powder Coat over Galvanizing
​
1B
Dark Bronze Powder Coat over Galvanizing
​
1Y
Dark Green Powder Coat over Galvanizing
​
1J
Grey Powder Coat over Galvanizing
​
XX
Special Powder Coat over Galvanizing
DRILL MOUNTING
*See Specification sheet for full details on all products
 |  |  |  |
|---|---|---|---|
 |  |  |  |
